Physics Edition
Thermal simulation
Tackle the thermal management of your design. Thanks to reliable results, you’ll avoid wasted time and unnecessary costs right from the start.
Simple operability, great benefits
Easily find thermal hotspots, critical trace resistances and excessive voltage drops – even before prototyping begins!
Thermal management even before prototyping
Avoid thermal problems from the start with PCB-Investigator Physics. Reliable simulations make this edition especially suitable for hardware engineers & electronics designers.
Benefits
Reliable simulations
Optimal production results by combining all features of the Developer Edition with reliable simulations
The perfect tool
Find thermal hotspots, critical trace resistances and excessive voltage drops – even in the design phase of the design
Extendable at any time
Simplify your work through automation and integrate your own plug-ins
Features
The Physics Edition includes the following features, among others:
- Transient thermal simulation with operating conditions
- Current density and voltage drop simulation
- Automation interface & script engine
- Additional import/export formats (e.g. GenCad, IDF, IPC2581)
- Bare board analysis (DRC)
- Creep current analysis
- Capacitance & impedance calculator
- Hazard Analysis
- Connector Analysis
Start with Physics now
Download the free trial version now or
get an individual offer from us!
